LC-Power LC500H-12 500W ATX Power Supply
The OFFICE SERIES by LC-POWER offers a good price-performance ratio: thanks to its 120mm fan, the LC500H-12 V2.2 lets you experience a stress-free and silent work in your office as well as at home. Despite the low sound level, the power supply offers a good cooling capacity for your system thanks to its honey-comb styled ventilation grille on its back. The power supply features all relevant connectors of the office sector.
|
Power supply type |
Office Series |
|
ATX standard |
ATX V2.2 |
|
Connectors |
|
|
20+4 pin mainboard |
1 x 45 cm |
|
4+4 pin mainboard 12V |
1 x 45 cm |
|
PCI-Express |
1 x PCI-Express 6 pin 45 cm |
|
SATA |
4 (2x 45 / 2x 60 cm) |
|
PATA |
2x 75 cm |
|
FDD |
1x 90 cm |
|
Mark of conformity |
CE |
|
Fan |
120 mm |
|
PFC |
active |
|
Dimension h x w x d |
85 x 150 x 140mm |
|
Weight (retail) |
1.392 kg |
|
Power rating |
500W max. / peak |
|
+3.3V |
20A |
|
+5V |
22A |
|
+12V1 |
15A |
|
+12V2 |
15A |
|
Standby consumption |
0,38W - ErP 2013 |
|
Temperature control for case fan |
Yes |
|
Security circuitry |
OVP = Over-Voltage Protection OPP = Over-Power Protection SCP = Short-Circuit Protection UVP = Under-Voltage Protection |
|
Full range (110V/220V) |
No |
|
Haswell compatible |
Yes |
| Colour | Grape |
|---|---|
| For | Desktop |
| Voltage | N/A |
| Amps | N/A |
| Wattage | 500W |
| Type | ATX |
