Digitus DS-45322 - Ultra Slim 2 Port HDMI Splitter - 1 Input <> 2 Output (4Kx4K)

Description

The DIGITUS high-performance HDMI Splitter splits your HDMI device’s audio and video signals on two screens, TVs or projectors with a resolution of UHD 4K / 60 Hz. No more tedious reconnecting your cables. Additionally, HDR, HDCP 2.2 and 3D are supported - also a total width of 18 Gbps for fluent playback in excellent quality. The HDMI splitter can be supplied via an existing USB port located on the TV device or, alternatively, via a USB charging adapter using electricity. You can cascade several splitters up to 8 levels.

Technical details

• Supports HDMI resolutions of up to 4K / 60 Hz (4096 x 2160p)
• Data transfer rate: 18 Gbps (6 Gbps per channel)
• Supports: RGB 4:4:4 / YCbCr 4:4:4 / YCbCr 4:2:2 / YCbCr 4:2:0
• Supports 36bit Deep Color (12 Gbps per channel)
• Supports HDCP 2.2 / 1.4
• Supports: 3D
• Supports: HDR (High Dynamic Range)
• Supports cascading of up to 8 splitters
• Operating temperature: 0°C ~ 45°C
• Operating humidity: 10% - 85% RH (non-condensing)
• Power consumption: 2 W (5 V/ 0.4 A)
• ESD protection: +/- 8 kV air insulation discharge, +/- 4 kV contact discharge
• Housing: Metal
• Colour: Black
• Weight: 60 g
• Dimensions: L 8.3 x W 4 x H 0.9 cm
• HDTV Resolution max.: 4096 x 2160 Pixel, 60Hz
• HDTV Standard: Ultra HD 4K
• Number of ports: 2
• Signal input: HDMI
• Signal output: HDMI

Package content

• Ultra Slim HDMI Splitter, 1x2, 4K / 60 Hz
• USB A on Micro USB connection cable (power supply)
• User manual
