Digitus CAT7 S-FTP (LS0H - Dca) Network Installation Cable (305m)
€241.90 €205.00
Availability: In stock
Only 2 left
SKU
370272
DESCRIPTION
The DIGITUS Cat.7 S/FTP installation cable is characterized by the following cable construction 4x2x AWG 26/1 and reaches a transmission frequency up to 1200 MHz. The halogen-free cable jacket conforms to the standard IEC 60332-3-24, FRNC-C, LSZH-3 and CPR Euro class Dca. The cable is suitable for laying in residential as well as SoHo areas.
Future-oriented standards and high-end quality for your network.
- 10GBit Ethernet
- 1200 MHz transmission frequency
- PoE Power over Ethernet support
- CPR class Dca-s1a,d0,a1
- Maxflex - maximum flexibility for your network cabling
TECHNICAL DETAILS
Physical properties |
|
| Conductor | Bare annealed copper, solid AWG 26/1 |
| Insulation | SFS-PE (Foam-Skin Polyethylene) |
| Total number of insulated conductors | 8, twisted in 4 pairs |
| Colour code | Blue-white, orange-white, green-white, brown-white |
| Individual pair shielding | Aluminum foil, providing 100 % coverage |
| Overall shielding | Copper wire braid |
| Outer sheath | Dca acc. to EN 50575; LSZH |
| Outer sheath diameter (nominal) | 0.52 mm nominal |
| Colour | White (RAL 9003) |
Mechanical properties |
|
| Tensile loading | 150N max. |
| Dynamic bending radius | 8x AD mm min. |
| Static bending radius | 4x AD mm min. |
| Shipping- and storage temperature range | -20 °C up to +75 °C |
| Operating temperature range | -20 °C up to +50 °C |
| Installation temperature range | 0 °C up to +50 °C |
| Overall diameter Simplex (nominal) | 5.7 mm nominal |
| Weight (kg/km) | 35 kg/km |
Electrical properties |
|
| Impedance | 100±15Ohm @ 4 - 100MHz; 100±25Ohm @ 100 - 600MHz |
| Capacitance | 45 pF/m nominal @ 1 KHz |
| Insulation resistance | 5 GOhm x km min. |
| DC resistance | 95 Ohm/km max. (2% max. resistance unbalance) |
| DC loop resistance | 190 Ohm/Km max. (2% max. resistance unbalance) |
| Voltage resistance | 72 Vdc max. |
Other |
|
| Coupling attenuation | CA-Type 1b |
| Signal propagation delay | 450 nS/100 m max. |
| Propagation delay | 25 nS/100 m max. |
| Separating class | “d” acc. to EN 50174-2 |
| NVP | 79% |
| Maximum operating length | 60 m |
| Assortment | Twisted Pair Installation Cables |
| Category | CAT 7 |
| Shielding | S-FTP, pairs in metal foil and braid shielding |
| CPR | Dca |
| Length | 305 m |
| Colour | white |
| Jacket | LSOH |
| Structure | 4 x 2 AWG 26/1, solid twisted pair |
| Colour | White |
|---|---|
| Type | CAT 7 |
| Length | 305 m |
| Shielding | S-FTP |
| Conductor | Bare Copper |
| Outdoor | No |
